Size | PR | Load Index Single/Dual | Load Range | Speed | Designed Outer Diameter | Designed Section Width | Tread Depth | Single | Dual | standard rim | ||
Kg | Kpa | Kg | Kpa | |||||||||
7.50R16LT | 16 | 125/121 | H | L | 803 | 212 | 12.4 | 1650 | 870 | 1450 | 870 | 6.00G |
12.00R24 | 20 | 160/157 | L | K | 1226 | 304 | 17.0 | 4500 | 900 | 4125 | 900 | 8.5 |
11R22.5 | 16 | 146/143 | H | L | 1047 | 272 | 15.0 | 3000 | 830 | 2725 | 830 | 8.25 |
12R22.5 | 18 | 152/149 | J | L | 1074 | 290 | 15.0 | 3550 | 930 | 3250 | 930 | 9.00 |
315/80R22.5 | 20 | 157/154 | L | L | 1076 | 310 | 16.0 | 4125 | 900 | 3750 | 900 | 9.00 |
