Size | PR | Load Index Single/Dual | Load Range | Speed | Designed Outer Diameter | Designed Section Width | Tread Depth | Single | Dual | standard rim | ||
Kg | Kpa | Kg | Kpa | |||||||||
11.00R20 | 20 | 153/150 | L | D | 1102 | 282 | 26.0 | 3650 | 970 | 3350 | 970 | 8.0 |
12.00R20 | 20 | 156/153 | L | D | 1136 | 302 | 24.8 | 4000 | 900 | 3650 | 900 | 8.5 |
12R22.5 | 18 | 152/149 | J | F | 1102 | 290 | 26.0 | 3550 | 930 | 3250 | 930 | 9.00 |
