Size | PR | Load Index Single/Dual | Load Range | Speed | Designed Outer Diameter | Designed Section Width | Tread Depth | Single | Dual | standard rim | ||
Kg | Kpa | Kg | Kpa | |||||||||
9.00R20 | 16 | 144/142 | H | D | 1032 | 260 | 24.5 | 2800 | 900 | 2650 | 900 | 7.0 |
10.00R20 | 18 | 149/146 | J | D | 1068 | 278 | 24.5 | 3250 | 930 | 3000 | 930 | 7.5 |
11.00R20 | 18 | 152/149 | J | D | 1088 | 286 | 25.0 | 3550 | 930 | 3250 | 930 | 8.0 |
12.00R20 | 20 | 156/153 | L | D | 1130 | 310 | 24.0 | 4000 | 900 | 3650 | 900 | 8.5 |
