Size | PR | Load Index Single/Dual | Load Range | Speed | Designed Outer Diameter | Designed Section Width | Tread Depth | Single | Dual | standard rim | ||
Kg | Kpa | Kg | Kpa | |||||||||
11R22.5 | 16 | 146/143 | H | L | 1039 | 272 | 11.0 | 3000 | 830 | 2725 | 830 | 8.25 |
12R22.5 | 18 | 152/149 | J | L | 1074 | 290 | 15.2 | 3550 | 930 | 3250 | 930 | 9.00 |
295/75R22.5 | 16 | 146/143 | H | L | 998 | 288 | 11.0 | 3000 | 830 | 2725 | 830 | 9.00 |
