High wear-resistance - High saturation pattern design, larger grounding area, opimized tread fomula provides excellent wear-resistance
Partial wear resistancelose -Optimized tread saturation and pattern block proporion distibution,enhance the ani-partial wear perfomance
Puncture resistance - Stone ejectors at groove bottom,effectively prevent the ditch bottom stone injury
Size | PR | Load Index Single/Dual | Load Range | Speed | Designed Outer Diameter | Designed Section Width | Tread Depth | Single | Dual | standard rim | ||
Kg | Kpa | Kg | Kpa | |||||||||
11R22.5 | 16 | 146/143 | H | L | 1050 | 272 | 16.5 | 3000 | 830 | 2725 | 830 | 8.25 |
12R22.5 | 18 | 152/149 | J | L | 1081 | 293 | 16.5 | 3550 | 930 | 3250 | 930 | 9.00 |
295/80R22.5 | 18 | 152/149 | J | M | 1042 | 295 | 16.8 | 3550 | 900 | 3250 | 900 | 9.00 |
315/80R22.5 | 20 | 157/154 | L | L | 1076 | 316 | 16.5 | 4125 | 900 | 3750 | 900 | 9.00 |
