Size | PR | Load Index Single/Dual | Load Range | Speed | Designed Outer Diameter | Designed Section Width | Tread Depth | Single | Dual | standard rim | ||
Kg | Kpa | Kg | Kpa | |||||||||
10.00R20 | 18 | 149/146 | J | K | 1054 | 272 | 16.5 | 3250 | 930 | 3000 | 930 | 7.5 |
11.00R20 | 18 | 152/149 | J | K | 1085 | 284 | 16.7 | 3550 | 930 | 3250 | 930 | 8.0 |
11R22.5 | 18 | 149/146 | J | L | 1054 | 270 | 16.5 | 3250 | 930 | 3000 | 930 | 8.25 |
12R22.5 | 18 | 152/149 | J | L | 1084 | 292 | 17.8 | 3550 | 930 | 3250 | 930 | 9.00 |
295/80R22.5 | 18 | 152/149 | J | L | 1045 | 292 | 16.8 | 3550 | 900 | 3250 | 900 | 9.00 |
215/75R17.5 | 16 | 135/133 | H | L | 766 | 212 | 13.5 | 2180 | 850 | 2060 | 850 | 6.00 |
315/80R22.5 | 20 | 157/154 | L | K | 1076 | 310 | 16.5 | 4125 | 900 | 3750 | 900 | 9.00 |
