Size | PR | Load Index Single/Dual | Load Range | Speed | Designed Outer Diameter | Designed Section Width | Tread Depth | Single | Dual | standard rim | ||
Kg | Kpa | Kg | Kpa | |||||||||
7.00R16LT | 14 | 118/114 | G | N | 775 | 198 | 12.4 | 1320 | 1180 | 5.50F | ||
7.50R16LT | 16 | 125/121 | H | L | 806 | 210 | 13.5 | 1650 | 870 | 1450 | 870 | 6.00G |
8.25R16LT | 18 | 132/128 | J | L | 860 | 230 | 15.0 | 2000 | 870 | 1800 | 870 | 6.50H |
12R22.5 | 18 | 152/149 | J | L | 1082 | 290 | 17.0 | 3550 | 930 | 3250 | 930 | 9.00 |
235/75R17.5 | 18 | 143/141 | J | J | 802 | 234 | 13.2 | 2725 | 875 | 2575 | 875 | 6.75 |
245/70R19.5 | 18 | 142/140 | J | K | 841 | 246 | 14.3 | 2650 | 900 | 2500 | 900 | 7.50 |
275/70R22.5 | 18 | 152/149 | J | J | 962 | 280 | 15.5 | 3550 | 900 | 3250 | 900 | 8.25 |
275/80R22.5 | 18 | 149/146 | J | L | 1015 | 280 | 16.5 | 3250 | 900 | 3000 | 900 | 8.25 |
295/60R22.5 | 18 | 150/147 | J | L | 926 | 292 | 17.3 | 3350 | 900 | 3075 | 900 | 9.00 |
